Parent Layer: Little Dry Creek Tribs Streams

Name: Catchments

Display Field: Str_Name

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: Streams, Catchments, and the Stream Management Corridor were deliverables from a project completed in to delineate streams that contain a minimum drainage area of 130 acres. The Arc Hydro toolset was used to identify and delineate these datasets using a 2.5ft resolution LiDAR DEM from DRCOG. The DRCOG LiDAR DEM was processed in 2013 and covers the majority of the MHFD boundary. DEMs from other municipal and state sources were used to complete coverage of the District extent. Datasets are updated as needed. Streams and catchments should be filtered using the definition query InOut_Dist = 'In'Critical Fields:Segment Number - autoincrements from downstream to upstream starting at 1. When a new junction point occurs the number goes to 2 and so onReach Code - established by MHFD years ago and is a four digit number starting with 0000 for the South PlatteTrib Code 1 - autoincrements from upstream to downstream starting at 1, unless a tributary comes in with an established reach codeTrib Code 2 to 7 - same as Trib Code1 for multiple branching tributariesMHFD Code - Seg_Num + Reach_Code + the Trib_Code (s)Legacy Code - Unique code from the MHFD's previous stream polyline layerRelated Datasets:MHFD SMCMHFD StreamsMHFD Streams Legacy

Service Item Id: 62aa02c85a7c47869c8eee13a76f2740

Copyright Text: Matrix Design Group, MHFD

Default Visibility: false

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0

Max Scale: 0

Supports Advanced Queries: true

Supports Statistics: true

Has Labels: true

Can Modify Layer: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports Datum Transformation: true

Extent:

XMin: 3136664.1547507043
YMin: 1620909.1623981728
XMax: 3184258.035294036
YMax: 1661314.1623046394
Spatial Reference: 103013  (6428)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [181, 241, 252, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:
Label Placement: esriServerPolygonPlacementAlwaysHorizontal
Label Expression: N/A
Use Coded Values: true
Symbol:
Color: [0, 0, 0, 255]
Background Color: N/A
Outline Color: N/A
Vertical Alignment: bottom
Horizontal Alignment: left
Right to Left: false
Angle: 0
XOffset: 0
YOffset: 0
Size: 10
Font Family: Tahoma
Font Style: normal
Font Weight: normal
Font Decoration: none

Min. Scale: 0.0
Max. Scale: 0.0

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: false
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false
Supports Percentile Statistics: true
Supports Having Clause: true
Supports Count Distinct: true
Supports Time Relation: true
Supports Sql Format: false
Supports Query Analytic: false
Supports Query With Current User: true

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field: null

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID )
• Shape ( type: esriFieldTypeGeometry, alias: Shape )
• Str_Name ( type: esriFieldTypeString, alias: Stream Name, length: 100 )
• Seg_Num ( type: esriFieldTypeInteger, alias: Segment Number )
• Reach_Code ( type: esriFieldTypeString, alias: Reach Code, length: 50 )
• Trib_Code1 ( type: esriFieldTypeInteger, alias: Trib Code1 )
• Trib_Code2 ( type: esriFieldTypeInteger, alias: Trib Code2 )
• Trib_Code3 ( type: esriFieldTypeInteger, alias: Trib Code3 )
• Trib_Code4 ( type: esriFieldTypeInteger, alias: Trib Code4 )
• Trib_Code5 ( type: esriFieldTypeInteger, alias: Trib Code5 )
• Trib_Code6 ( type: esriFieldTypeInteger, alias: Trib Code6 )
• Trib_Code7 ( type: esriFieldTypeInteger, alias: Trib Code7 )
• MHFD_Code ( type: esriFieldTypeString, alias: MHFD Code, length: 50 )
• LegacyCode ( type: esriFieldTypeString, alias: Legacy Code, length: 25 )
• Seg_ID ( type: esriFieldTypeString, alias: Segment ID, length: 25 )
• Section_ID ( type: esriFieldTypeString, alias: Section, length: 50 )
• Catch_Acre ( type: esriFieldTypeDouble, alias: Acreage )
• InOut_Dist ( type: esriFieldTypeString, alias: In District, length: 3 )
• Shape_Length ( type: esriFieldTypeDouble, alias: Shape_Length )
• Shape_Area ( type: esriFieldTypeDouble, alias: Shape_Area )
